Name: CSF High Performance Aluminium Radiator BMW E9X M3
Brand: CSF
SKU: CSF-7059
Price: 768.00 GBP
Availability: InStock

Product Description

The CSF High-Performance Triple Pass All-Aluminium Radiator is a premium cooling upgrade for the BMW E9X M3, designed to improve cooling efficiency for high-performance road driving, track use and high-horsepower builds.

Built with CSF’s advanced B-Tube Technology, this radiator uses a 2-row 42mm core with specially engineered “B” shaped tubes to increase heat transfer surface area by approximately 15% compared with conventional tubes. This helps improve coolant flow and overall thermal efficiency.

The triple-pass flow structure forces coolant to travel across the core three times before exiting, helping achieve lower outlet temperatures and more stable engine cooling under sustained load.

With an ultra-efficient multi-louvered fin design, CNC-machined brackets and fittings, an all-aluminium race-style drain plug and a smooth satin finish, this radiator combines performance, durability and direct-fit installation for the S65-powered E9X M3.

Key Features

CSF High-Performance Triple Pass All-Aluminium Radiator
Designed for BMW E9X M3
Suitable for S65 4.0L V8 engines
High-performance cooling upgrade
Ideal for high-performance street driving
Ideal for demanding track conditions
Suitable for high-horsepower builds
Suitable for motorsport use
Triple-pass flow structure
Coolant flows across the core three times before exiting
Helps reduce outlet temperatures
Supports optimal engine cooling
2-row 42mm core
CSF exclusive B-Tube Technology
“B” shaped tubes increase heat transfer surface area
Approximately 15% more heat transfer surface area than conventional tubes
Dual liquid laminar flow
Superior cooling efficiency
Ultra-efficient fin design
6.5mm fin height
Multi-louvered fin design
Designed to maximise airflow
Designed to maximise heat rejection
Wind-tunnel tested by CSF
All-aluminium construction
CNC-machined brackets and fittings
All-aluminium race-style drain plug
Smooth satin finish
True drop-in fit
No modifications required
Accepts OEM quick-connect hoses
Accepts OEM AC condenser
Accepts OEM mounting brackets
Accepts OEM fan shroud
Replaces OEM Part Number 17112283468

Vehicle Compatibility

BMW E90 M3 4.0L V8 2008–2013
BMW E92 M3 4.0L V8 2009–2013
BMW E93 M3 4.0L V8 2009–2013
Replaces OEM BMW Part Number 17112283468.
Please confirm exact vehicle model, production year, engine, cooling system condition and OEM radiator part number before ordering.

What's Included

CSF High-Performance Triple Pass All-Aluminium Radiator
2-row 42mm aluminium radiator core
Triple-pass radiator design
CNC-machined brackets and fittings
All-aluminium race-style drain plug
OEM-style mounting provisions
Coolant, hoses, thermostat, fan shroud, AC condenser, mounting hardware, fitting consumables and additional cooling components are not included unless supplied separately.

FAQs

What does the CSF High-Performance Radiator do?

It replaces the factory radiator with a higher-efficiency all-aluminium radiator designed to improve cooling performance and maintain stable engine temperatures under load.

Which vehicles does it fit?

It fits BMW E90, E92 and E93 M3 models with the 4.0L V8 engine.

Which OEM part number does it replace?

It replaces OEM BMW Part Number 17112283468.

Is it suitable for track use?

Yes. It is designed for demanding track conditions, high-performance street driving and motorsport use.

Is it suitable for high-horsepower builds?

Yes. The supplied information states that it is essential for high-horsepower builds and motorsports.

What is B-Tube Technology?

CSF’s B-Tube Technology uses specially engineered “B” shaped tubes to increase heat transfer surface area and improve cooling efficiency.

How much more surface area does the B-Tube design provide?

The supplied information states that it increases heat transfer surface area by approximately 15% over conventional tubes.

What does triple-pass mean?

Triple-pass means the coolant flows across the radiator core three times before exiting, helping reduce outlet temperatures and improve cooling performance.

What size is the core?

The radiator uses a 2-row 42mm core.

What type of fin design does it use?

It uses a 6.5mm fin height with a multi-louvered design to maximise airflow and heat rejection.

Is it a direct-fit radiator?

Yes. It is described as a true drop-in fit with no modifications required.

Does it work with OEM components?

Yes. It accepts OEM quick-connect hoses, AC condenser, mounting brackets and fan shroud.

What is it made from?

It uses all-aluminium construction with CNC-machined brackets and fittings.

Does it include a drain plug?

Yes. It includes an all-aluminium race-style drain plug.

What should I check before ordering?

Please confirm your exact BMW M3 model, body style, production year, 4.0L V8 engine fitment, OEM radiator part number and cooling system condition before ordering.
